For inventory inquiries, please contact your local branch at (214) 630-8360- Body Configuration : 1 SUP / 8 DEL (6H + 2V)
- Cautionary Note(s) : Use caution when positioning solenoid connector.
- Connector Type : 2-Way Circular DIN (ISO 15170-1 Twist-Lock)
- Control Port : 1/4-18 NPT
- Control Port Orientation (CW from Front Face) : 0 deg
- Crack Pressure : 4.0 PSI
- Delivery Port 1 : 1/2-14 NPT
- Delivery Port 2 : 1/2-14 NPT
- Delivery Port 3 : 1/2-14 NPT
- Delivery Port 4 : 1/2-14 NPT
- Delivery Port 5 : Closed Port
- Delivery Port 6 : Closed Port
- Delivery Port 7 : 3/8-18 NPT
- Delivery Port 8 : 3/8-18 NPT
- Exhaust Port : Dust Shield
- Internal Supply Passage to Cover : Yes
- Maximum Operating Temperature : 185 deg F (85 deg C)
- Minimum Operating Temperature : -40 deg F (-40 deg C)
- Mounting : 3/8-16 UNC-2B (3x)
- Mounting Orientation (CW from Front Face) : 180 deg
- Supply Port 1 : 1/2-14 NPT
- TMC Washer : RV040
- Voltage (Nominal) : 24 Volts
- Warranty Time Period1 YearWarranty Mileage100,000 miles
