- Air Dryer Type : Stand-Alone
- Body Mounting : 3/8-16 UNC-2B (4x)
- Cartridge Thread : 1 1/4-7 UNC-2B
- Cartridge Type : Standard
- Clearance to Remove Cartridge : .50 IN
- Control Port : 1/4-18 NPT
- Delivery Port 1 : 1/2-14 NPT
- Extended Purge Port : 1/8-27 NPT (Plugged)
- Governor Included : No
- Heater / Thermostat Rating : 12V / 90W
- Heater Connector Color : White
- Heater Connector Type : Metri-Pack 280 Series 2-Way Sealed Connector (Male)
- Lower Mounting Bracket : .41 IN x 1.15 IN Slot (2x)
- Lower Mounting Bracket Angle (CCW from SUP) : Loose in Box
- Maximum Inlet Temperature : 160 deg F (71 deg C)
- Minimum Operating Temperature : -40 deg F (-40 deg C)
- Purge Exhaust Port : Standard
- Purge Valve Type : Hard Seat
- Purge Volume : Standard
- Safety Valve Opening Pressure : 200 PSI
- Supply Port : 1/2-14 NPT
- Upper Mounting Bracket : .41 IN x 1.15 IN Slot (2x)
- Upper Mounting Bracket Height (from Lower Mounting Bracket) : Loose in Box
- Upper Mounting Type : Cable
- 065624
