Pickup
Not availableat Dallas, TX
Shipping
Not available to 75247
For inventory inquiries, please contact your local branch at (214) 630-8360- 60 °ball end for ADB chambers4.75 inM16 x 1.52.25 inNone18All vent holes must be open243/8 in-180.59 inNo1.72 in12.98 lb1.72 inStandard
- Cautionary Note(s) : All vent holes must be open
- Chamber Style : Double Diaphragm
- Chamber Type / Size : T18/24
- Clamp Angle : 270 deg
- Maximum Operating Temperature : 176 deg F (80 deg C)
- Minimum Operating Temperature : -40 deg F (-40 deg C)
- Mounting Stud Length : 1.72 IN (43.7 MM)
- Parking Chamber Sealed : No
- Parking Port (12) : 3/8-18 NPTF
- Port Angle : 60 deg
- Push Rod Length [MM] : 15
- Push Rod Thread / Style : Spherical End
- Service Chamber Joint Type : Single Clamp Band
- Service Chamber Vent Holes : All Open
- Service Port (11) : 3/8-18 NPTF
- Stroke : 2.25 IN (57.2 MM)
- Stud Spacing : 4.75 IN (120.7 MM)
- Stud Thread Size : M16 x 1.5-6g
