For inventory inquiries, please contact your local branch at (214) 630-8360- Drum3/8 in-181.48 in1.00 in135 °305/8 in-185/8 in-11304.75 in3.00 inNoNoneDo not disassemble while park side is caged under pressure1.48 in20.50 lb45 °
- Brand : EnduraSure
- Cautionary Note(s) : Do not disassemble while park side is caged under pressure
- Chamber Style : Double Diaphragm
- Chamber Type / Size : T30/30
- Clamp Angle : 45 deg
- Clevis / Yoke Style : Not Included
- Maximum Operating Temperature : 175 deg F (79 deg C)
- Minimum Operating Temperature : -40 deg F (-40 deg C)
- Mounting Stud Length : 1.48 IN (37.5 MM)
- Parking Port (12) : 3/8-18 NPTF
- Port Angle : 135 deg
- Push Rod Length (to Yoke Pin Center when Applicable) [IN] : 1.00
- Push Rod Thread / Style : 5/8-18 UNF-2A
- Service Chamber Joint Type : Double Clamp Band
- Service Port (11) : 3/8-18 NPTF
- Stroke : 3.00 IN (76 MM)
- Stud Spacing : 4.75 IN (120.7 MM)
- Stud Thread Size : 5/8-11 UNC-2A
