Product Details: Manufacturer Part Number: 5504268|Relief Angle|7Corner Radius (mm)|Corner Radius (Inch)|1/64Corner Radius (Decimal Inch)|0.0157Included Angle|55.0Manufacturer Grade|IC507Coating/Finish|TiCN; TiNWiper Edge|Insert Hand|Insert Thickness|Insert Thickness (Inch)|5/32Insert Thickness (Decimal Inch)|0.1563Series|IsoturnInscribed Circle (Inch)|3/8Inscribed Circle (Decimal Inch)|0.3748Inscribed Circle (mm)|Insert Material|Solid CarbideInsert Shape|DiamondChipbreaker Operation|Grade Characteristics|Number Of Cutting Edges|Insert Shape Code|DSingle Or Double End|Hole Diameter (Decimal Inch)|0.1732Hole Diameter (Mm) ( - 0 Decimals)|4.40Maximum Depth of Cut (mm)|2.50Maximum Depth of Cut (Decimal Inch)|0.0984Maximum Depth of Cut (Fractional Inch)|Insert Holding Method|ScrewWidth (Inch)|Clearance Code|CTolerance Code|MCoating Process|PVDLength Range (Decimal Inch)|0.4000 - 0.5000Rake|PositiveInsert Length (mm)|11.60Insert Length (Decimal Inch)|0.4567Insert Length (Inch)|Primary Workpiece Material|UniversalPrimary Workpiece Material Code|H; M; P; SSecondary Workpiece Material|Secondary Workpiece Material Code|Ansi Code|Iso Code|ISO 13399Standards|ISO 13399Manufacturers Catalog Number|Cutting Direction|Material Grade|SubmicronSingle or Multi Tipped|Stocking Category|Proprietary Coating Designation|Lead Angle|Coating Classification|Chip Breaker|SMRake Angle|Cutting Edge Style|Style|Industry Standard Number|Width (Decimal Inch - 4 Decimals)|Width (mm - 2 Decimals)|Multi-Use Tool|Full Radius|Multi-Use Application|Tip Length (Decimal Inch)|Tip Length (mm)|ANSI Size Code|ISO Size Code|System Of Measurement|Product Service Code|UNSPSC Code|Insert Style|DCMTInsert Size Code|3-1
