Manufacturer Part Number: 1865953|Insert Style|RCMKInsert Size Code|35Insert Material|CarbideMaterial Grade|P10; P20; M10; M20; K05; K10; K15; K20; N10; N20; S10; S20; H10Width (Inch)|3/8Manufacturer Grade|KC5010Thickness (Inch)|Insert Height (Decimal Inch)|0.5210Thickness (mm)|13.23Insert Height (mm)|13.23Maximum Depth of Cut (Decimal Inch)|0.1875Maximum Depth of Cut (mm)|Insert Holding Method|Clamp; PinInsert Hand|NeutralCorner Radius (Decimal Inch)|0.1875Corner Radius (mm)|Included Angle|360Relief Angle|5Chipbreaker|NoneInscribed Circle (Inch)|3/8Inscribed Circle (Decimal Inch)|0.3750Inscribed Circle (mm)|Series|K-LOCKCoating Process|PVDRake|PositiveInsert Length (Decimal Inch)|0.3750Insert Length (mm)|13.23Insert Length (Inch)|3/8Number Of Cutting Edges|4Hole Diameter (Decimal Inch)|0.0000Hole Diameter (Mm) ( - 0 Decimals)|Primary Workpiece Material|Steel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard MaterialPrimary Workpiece Material Code|P; M; K; N; S; HSecondary Workpiece Material|Secondary Workpiece Material Code|Ansi Code|Iso Code|RCMK090700Standards|RCMK35; RCMK090700Rake Angle|7Side Length (Decimal Inch)|0.3750Side Length (mm)|Shape|RoundApplications|Profiling; TurningMSC/Manufacturer Number|RCMK35Coating Classification|PVDCoating/Finish|AlTiNThickness (Decimal Inch - 4 Decimals)|0.5210Width (Decimal Inch - 4 Decimals)|0.3750Width (mm - 2 Decimals)|UNSPSC Code|23242105
