Name: MGM Brakes 3030 Long Stroke Spring Brake Chamber with 2.25" Push Rod
Brand: MGM BRAKES
SKU: MGM-3231951
Price: 234.99 USD
Availability: InStock

MGM Brakes 3030 Long Stroke Spring Brake Chamber with 2.25" Push Rod

Part #: 3231951|Brand: MGM BRAKES|MPN #: 3231951

$234.99

/ ea

MGM Brakes 3030 Long Stroke Spring Brake Chamber with 2.25" Push Rod

Part #: 3231951|Brand: MGM BRAKES|MPN #: 3231951

$234.99

/ ea

Available to transfer

Pick up est. Oct 31 Dallas, TX

Ready to ship PARCEL ELIGIBLE

Get it est. 31 Oct to 75247

Check Nearby Stores

Stroke Type:
Long
Service Size Type:
30
Clevis Included:
Yes
Chamber Type:
Spring combination
Brake Type:
Drum
Spring Size Type:
30
Distance To Large Clevis Pin Center From Service Housing Face:
2.25
Notes:
Double Diaphragm - Long Stroke - Parking Brakes
Clevis Type:
Welded
Stroke Length:
3.00 in
Mounting Stud Spacing (Center to Center):
4.75 in
Mounting Stud Threads:
5/8 in-11
Diaphragm Material:
Nylon Reinforced Neoprene
Mountind Stud Length:
1.54 in
Pushrod Length:
2.25 in
Clevis Pin Center to Service Housing Face Distance:
2.25 in
Piggyback Length:
7.61 in
Pushrod Threads:
5/8 in-18
Mounting Stud Length:
1.54 in
Port Size:
3/8 in-18
Weight:
20.01 lb
Service Housing Outer Diameter:
8.32 in
Chamber Housing Length:
9.99 in
VMRS:
013004027
Prepare your semi to be Ready for the Road Ahead™, with the MGM Brakes 3030 Long Stroke Spring Brake Chamber that provides enhanced brake safety. Due to its pressurized inner chamber, this replacement component is able to apply the spring brakes as a safety measure once the internal air pressure drops below a certain level. Constructed with a rugged metal body to efficiently contain pressure and the energized spring brakes.

FleetPride is your First Click in Heavy Duty®.
Designed to be tamper resistant

Molded nitrile rubber air seal

Heavy duty nylon reinforced diaphragm

Outfitted with an epoxy-coated head, non-pressure chamber, and lower push-rod assembly

Designed with a weather seal plug

External breather tube

Square Port Bosses (Long Stroke Identification)

3" long stroke
