Manufacturer Part Number: 5915049|Relief Angle|0Corner Radius (mm)|0.80Corner Radius (Inch)|1/32Corner Radius (Decimal Inch)|0.0315Included Angle|80Manufacturer Grade|S05FCoating/Finish|Al2O3; TiCN; Titanium NitrideWiper Edge|NoInsert Hand|NeutralInsert Thickness|4.76Insert Thickness (Inch)|3/16Insert Thickness (Decimal Inch)|Series|T-Max PInscribed Circle (Inch)|1/2Inscribed Circle (Decimal Inch)|0.5000Inscribed Circle (mm)|12.70Insert Material|CarbideInsert Shape|DiamondChipbreaker Operation|Grade Characteristics|Number Of Cutting Edges|4Insert Shape Code|CSingle Or Double End|Hole Diameter (Decimal Inch)|0.2032Hole Diameter (Mm) ( - 0 Decimals)|5.16Maximum Depth of Cut (mm)|8.50Maximum Depth of Cut (Decimal Inch)|0.3346Maximum Depth of Cut (Fractional Inch)|Insert Holding Method|Clamp; PinWidth (Inch)|Clearance Code|NTolerance Code|MCoating Process|CVDLength Range (Decimal Inch)|0.5000 - 0.6000Rake|Insert Length (mm)|12.90Insert Length (Decimal Inch)|0.5079Insert Length (Inch)|Primary Workpiece Material|Superalloy; TitaniumPrimary Workpiece Material Code|SSecondary Workpiece Material|Secondary Workpiece Material Code|Ansi Code|Iso Code|CNMG 12 04 08-SM S05FStandards|Manufacturers Catalog Number|5915049Cutting Direction|Material Grade|Single or Multi Tipped|Stocking Category|Proprietary Coating Designation|Lead Angle|Coating Classification|Chip Breaker|SMRake Angle|Cutting Edge Style|Style|Industry Standard Number|Width (Decimal Inch - 4 Decimals)|Width (mm - 2 Decimals)|Multi-Use Tool|Full Radius|Multi-Use Application|Tip Length (Decimal Inch)|Tip Length (mm)|ANSI Size Code|ISO Size Code|System Of Measurement|Product Service Code|UNSPSC Code|23242105Insert Style|CNMGInsert Size Code|432
