Manufacturer Part Number: 5742013|Thread Type|Internal; ExternalHand of Holder|Right HandShank Width/Diameter (Decimal Inch)|0.6250Compatible Insert Size Code|Shank Width/Diameter (mm)|Shank Width/Diameter (Inch)|5/8Toolholder Style|R166.0KF..CInsert Compatibility|R166.0L to 11Coolant Entry Style Code|Insert Holding Method|Clamp & ScrewShank Height (mm)|14.48Shank Height (Decimal Inch)|0.5700Shank Height (Inch)|Shank Length (Inch)|5Shank Length (mm)|Shank Length (Decimal Inch)|5.0000Overall Length (mm)|Overall Length (Inch)|5Overall Length (Decimal Inch)|5.0000Minimum Bore Diameter (Decimal Inch)|0.5000Minimum Bore Diameter (mm)|Minimum Bore Diameter (Inch)|Multi-use Tool|Cutting Tool Application|Head Length (Inch)|Head Length (Decimal Inch)|0.8189Head Length (mm)|20.80Maximum Depth of Cut (Decimal Inch)|0.8189Maximum Depth of Cut (mm)|Adjustable Overhang|Minimum Overhang (Decimal Inch)|Maximum Overhang (Inch)|Back of Bar to Cutting Edge (Inch)|5Back of Bar to Cutting Edge (Decimal Inch)|5.0000Back of Bar to Cutting Edge (mm)|Center to Cutting Edge (mm)|10.01Center to Cutting Edge (Decimal Inch)|0.3940Insert Inscribed Circle (Decimal Inch)|0.2500Insert Inscribed Circle (Inch)|1/4Insert Inscribed Circle (mm)|Primary Workpiece Material|Primary Workpiece Material Code|Secondary Workpiece Material|Secondary Workpiece Material Code|Standards|Neck Diameter (Decimal Inch)|0.6250Pitch Range|Coolant Hole Diameter (Decimal Inch)|Coolant Hole Thread Size (Inch)|Product Service Code|Toolholder Material|SteelUNSPSC Code|23291800Contents|Manufacturers Catalog Number|MSC/Manufacturer Number|Distance Across Flats|Head Width (Inch)|Insert Thickness (Decimal Inch)|Number of Inserts Included in Order|Style|D -In--|Coolant Through|NoF -In--|Series|T-Max U-Lock
