Manufacturer Part Number: 02430360|Relief Angle|7Corner Radius (mm)|Corner Radius (Inch)|Corner Radius (Decimal Inch)|0.0039Included Angle|55degreeManufacturer Grade|CP500Coating/Finish|TiAlN; TiNWiper Edge|NoInsert Hand|NeutralInsert Thickness|Insert Thickness (Inch)|5/32Insert Thickness (Decimal Inch)|0.1563Series|DCGT-F1Inscribed Circle (Inch)|3/8Inscribed Circle (Decimal Inch)|0.3750Inscribed Circle (mm)|Insert Material|CarbideInsert Shape|Diamond 55Chipbreaker Operation|Grade Characteristics|Number Of Cutting Edges|2Insert Shape Code|DSingle Or Double End|Hole Diameter (Decimal Inch)|0.1772Hole Diameter (Mm) ( - 0 Decimals)|Maximum Depth of Cut (mm)|Maximum Depth of Cut (Decimal Inch)|0.4528Maximum Depth of Cut (Fractional Inch)|Insert Holding Method|ScrewWidth (Inch)|3/8inClearance Code|CTolerance Code|GCoating Process|PVDLength Range (Decimal Inch)|0.7000 - 10.0000Rake|PositiveInsert Length (mm)|Insert Length (Decimal Inch)|0.9134Insert Length (Inch)|Primary Workpiece Material|Stainless SteelPrimary Workpiece Material Code|MSecondary Workpiece Material|Steel; Cast Iron; Super-alloys & TitaniumSecondary Workpiece Material Code|P; K; SAnsi Code|Iso Code|DCGT11T301-F1Standards|ANSI; ISOManufacturers Catalog Number|02430360Cutting Direction|Material Grade|M10; M20; M30Single or Multi Tipped|Stocking Category|Proprietary Coating Designation|Multilayer CoatingLead Angle|55degreeCoating Classification|PVDChip Breaker|F1Rake Angle|Cutting Edge Style|SharpStyle|Industry Standard Number|DCGT32.50-F1Width (Decimal Inch - 4 Decimals)|0.3750inWidth (mm - 2 Decimals)|Multi-Use Tool|YesFull Radius|NoMulti-Use Application|Back Turning; Boring; Facing; TurningTip Length (Decimal Inch)|Tip Length (mm)|ANSI Size Code|ISO Size Code|System Of Measurement|Product Service Code|UNSPSC Code|23242105Insert Style|DCGTInsert Size Code|32.50
